GTT Delta Elite - 4port Torch - with Compressed Air Option
Compressed air injection technology injects compressed air directly into the fuel system of the torch. By precisely controlling the ratio of fuel and compressed air, the temperature of the flame can be controlled while maintaining flame chemistry and flame type. From the cooler, driving flame to the wide bushy cool flame, any combination is now possible. Thin hollow work is now easier and more controllable than ever before. Colors that are tough to work become easier than ever before and appear sharper and true to form. And if that’s not enough, this setup is foot pedal ready! Now, not only can each stage of the torch be individually controlled, but each stage of compressed air injection can now be controlled with a foot pedal.
Triple mix technology combined with compressed air injection adds a new dimension to the flame characteristics that no other torch on the market can achieve. GTT compressed air systems encompass everything GTT is known for; quality, safety, versatility, outstanding engineering and unsurpassed functionality.
Two options for compressed air - tanked air or air compressor tanked air. Tanked air simply requires a tank, regulator and hose. The compressed air in the tank has been filtered, dried and compressed so there is no need for anything other equipment in the system. The benefit is a simpler system without filters or dryer maintenance and initial cost. The drawback is the same as all other tanked gasses, tanks run out, tanks are heavy, and they are a constant expense.
Compressed air system warnings
*Only clean, dry compressed air is to be used with this system. If moisture or dirt enters the system from the compressed air supply, it will void all warranties.
*Do not remove any components from the system
*Pre-installed check valves are required for safety - do not modify or remove.
*Compressed air hose supplied with the torch is fire resistant - do not replace with any other type of hose.
*Close all torch valves and compressed air shutoff valve when not in use.
*Maximum air pressure must not exceed 100 psi.
*Check that all system components are in good operating condition before using this product.
The Delta Elite comes with 1' of 3/16" hose and adaptors with filter screens to adapt to standard 1/4" ID grade "T" hose on each stud. The adaptors have a barb that the 1/4" ID grade "T" hose slides over and is clamped securely. The Delta Elite comes standard with a purple manifold, red, blue and green valve caps and rack and pinion adjustment. It is mounted on a powder coated base that has holes for securing the base to the work table. Also included are complete instructions, a cleaning kit, and an instructional DVD.
